DURAN® GL 45 Connection Cap System, with screw cap and 2 or 3 GL 14 ports, PP, blue/grey

• Manufactured from Polypropylene with Viton (fluoropolymer elastomer) O-ring seal
• Rigid or semi-rigid tubing of different diameters can be accommodated by using a blue GL 14 open topped cap with one of the inserts.
• Available with 2, or 3 threaded outlets (ports).
• Four different tubing diameters (1.6 mm, 3.0 mm, 3.2 mm or 6.0 mm tubing outer diameter) can be used by changing the GL 14 inserts.
• By applying positive or negative pressure liquid can be pumped out of or into the bottle via the screw cap.
• Fully compatible with all the GL 45 threads and therefore highly versatile.

Product Overview

Flexible modular GL 45 connection cap system that accepts four different rigid or semi-rigid tubing diameters (1.6 mm; 3.0 mm; 3.2 mm and 6.0 mm). The caps are available with 2 or 3 GL 14 threaded ports. The different sized inserts form a tight seal around the pass-through tubing. Sterile pressure equalisation is possible through use of 0.2 µm syringe filter. Unused ports can be sealed off with a red GL 14 screw cap.

Varian GL 45 Connection Cap System, with Screw Cap yang tersedia (wajib pilih yang tersedia di kolom varian):

• 2 Port GL14, PP, Colour Blue-Grey (Cat.No. 1129750).
• 3 Port GL14, PP, Colour Blue-Grey (Cat.No. 1129751).

DURAN® GL 45 Connection Cap and Stirred Bottle Reactor System, (accessories & replacement parts)

• Manufactured from PP, PTFE, silicone
• Accessories designed for use with the DURAN® GL 45 2/3 port tubing connection caps or GL 45 / GLS 80® Stirred Bottle Reactor caps
• Safe and secure liquid transfer into or out of laboratory bottles
• Four inserts are suitable for rigid or semi-rigid tubing with a range of outer diameters: 1.6, 3.0, 3.2 or 6.0 mm
• Open-topped blue PP GL 14 pass-through tubing cap for use with the inserts
• Closed-top red PBT GL 14 cap for sealing unused ports
• Sterile pressure equilisation is possible with pressure compensation set

Varian yang tersedia (wajib pilih yang tersedia di kolom varian):

• GL 14 Screw Cap Open Top, for Tube Connection, PP, Colour Blue (Cat.No. 1129814).
• Insert for GL14 Screw Cap, Inner diameter 1.6mm (1/16 inch), Silicone/PTFE (cat.No. 1129815).
• Insert for GL14 Screw Cap, Inner diameter 3.0mm (~1/8 inch), Silicone/PTFE (cat.No. 1129816).
• Insert for GL14 Screw Cap, Inner diameter 3.2mm (1/8 inch), Silicone/PTFE (cat.No. 1129817).
• Insert for GL14 Screw Cap, Inner diameter 6.0mm (~1/4 inch), Silicone/PTFE (cat.No. 1129818).
• Replacement 0.2 µm Syringe Disc Filter, for Pressure Equalization Set (cat.No. 1129819).
• GL 14 Blanking Screw Cap with PTFE Coated Silicone Seal, PBT, Colour Red (cat.No. 1156292).
• GL 14 Pressure Equalization Set, for GL 45 2 or 3 port screw cap, incl. 0.2 µm membrane filter (cat.No. 1137799).
