DURAN® TILT GL 56 Media Preparation Bottle (clear glass)

Catalog no 218914459

Diameter 124 mm

Height 148 mm

with screw cap (PP, white)

• Manufactured from borosilicate glass 3.3, polypropylene
• Unique 45° TILT position for easy pipetting without holding the bottle
• Low bottle height for easy handling in safety cabinets
• The wide GL 56 mouth ensures safe and easy pipetting and helps avoid contamination
• Tilted volume indicators, visible from both sides for convenience of left and right-handed users
• Space saving shape for fridge storage and usage in water baths
• Accommodates even large volume pipettes (100 ml)
• Vacuum resistant bottle for safe filter sterilisation
• The ergonomic cap, made from non-cytotoxic materials, is easy to open and close
• Award winning design. 2016 GOOD DESIGN® Award from the Chicago Athenaeum Museum of Architecture and Design



Product Overview

Biosafety cabinets and clean hoods are essential for working with cell cultures under sterile conditions. Unfortunately, they make the handling of media bottles difficult and time-consuming for researchers. The award wining DURAN® TILT bottle changes everything. The TILT bottle has two positions: upright for filter sterilization or storage, and tilted at 45° for pipetting. Take a look at cell culture media from a new angle and discover a bottle system that eases handling and turns usability into security.



DURAN® TILT GL 56 Screw Cap, PP, white

Catalog no 292295602

Diameter 62 mm

Height 27 mm

• Manufactured from Polypropylene
• The ergonomic cap, made from non-cytotoxic materials, is easy to open and close
• The wide GL 56 mouth ensures safe and easy pipetting and helps avoid contamination



Product Overview

The ergonomic cap is easy to open and close. Made from non-cytotoxic materials. The wide mouth ensures safe and easy pipetting.



DURAN® TILT GL 56 Bottle Tag, silicone rubber

Varian Colour :

• Orange, catalog no 292435626
• Yellow, catalog no 292435634
• Blue, catalog no 292435659
• Purple, catalog no 292435667



• Manufactured from silicone rubber
• The Bottle Tags can be used for colour identification or to secure the protective Light Shield around the bottle
• The elastic Bottle Tags can be easily and securely attached around the neck, even with the screw cap in place
• Feature a graspable tab that makes them easy to remove with bare or gloved hands
• Chemically robust, heat resistant and reusable



Product Overview

The Bottle Tags can be used on their own for colour identification or to secure the protective Light Shield around the bottle. The GL 56 Bottle Tags are available in four colours: orange, yellow, blue and purple.



TILT BOTTLE TOP FILTER UNIT 500 mL, GL 45

Material Bottle Top Filtration Unit : Polystyrene

Varian :

• Tilt Bottle Top Filtration Unit, PES, 0.1um
• Tilt Bottle Top Filtration Unit, PES, 0.2um
• Tilt Bottle Top Filtration Unit, PES, 0.45um



DURAN® TILT GL 45 to GL 56 Thread Adaptor, PTFE, white

Catalog no 291195601

Thread : GL 45 / GL 56

Diameter 65 mm

Height 46 mm

Colour White

• Manufactured from inert PTFE
• The reusable adaptor (GL 45 external/GL 56 internal) allows the use of the DURAN® TILT bottle with 45 mm filter units for the filter sterilisation of cell culture media
• Allows any 45 mm filter units to be used with DURAN® TILT bottle

Product Overview

The re-usable adaptor (GL 45 external / GL 56 internal) allows the use of the DURAN® TILT bottle with 45 mm filtration units for the filter sterilisation of cell culture media. Manufactured from inert PTFE; can be autoclaved and depyrogenised at 300 °C.





DURAN® TILT Bottle Light Shield, silicone rubber, white

• Manufactured from silicone
• The white DURAN® TILT Light Shield is a silicone sleeve that covers 94 % of the bottle surface and blocks damaging ultraviolet light
• Protects the glass surface from damage
• Facilitates safer handling
• Silicone provides a much better grip than glass especially when the bottle has been sprayed with 70 % alcohol for surface disinfection



Product Overview

The DURAN® TILT Light Shield is a white silicone sleeve that covers 94% of the bottle surface. The sleeve has a number of protective functions: it blocks damaging ultraviolet light (UV), protects the glass surface from damage, and facilitates safer handling. DURAN® TILT Light Shield includes four GL 56 Bottle Tags (Orange, Yellow, Blue, Purple) made from silicone.
