DURAN® YOUTILITY® GL 45 Laboratory Bottle (clear)

with screw cap and pouring ring (PP, cyan), with DIN 168-1 thread, graduated

• Easier and safer handling with the award winning design. Specially shaped gripping zones on both sides of the bottle
• Manufactured from DURAN® borosilicate glass 3.3. DURAN® is a neutral glass, classified as a Glass Type I according to USP <660>, EP (3.2.1) and JP <7.01>, and meets ASTM E438, Type I, Class A requirements
• The optimized, ergonomic shape of the screw cap has comfortable grooves and ridges for a more efficient and easier tightening or removal, especially with smaller sized or gloved hands
• Significantly faster opening or closing with the shortened bottle thread which remains fully compatible with GL 45 closures and other accessoires
• The pre-defined labelling areas are compatible with the dedicated DURAN® self-adhesive YOUTILITY bottle labels for unambigious bottle identification
• Space-saving design. The slimmer bottle shape allows a more optimal use of limited space in autoclaves and laboratory refrigerators
• The tried and tested cap plug sealing with sealing lip system ensures a liquid tight seal
• Easy-to-read scale with graduation marks to estimate the content
• Lot number (Retrace code) for traceability and certificate download at https://cert.dwk.com/
• Award winning product design. Winner of seven international awards: Red Dot 2014, iF 2014, Silver IDEA International Excellence Award 2014, GOOD DESIGN AWARD Japan 2014, Special Mention German Design award 2015, Nominert DESIGNPREIS DER BUNDESREPUBLIC DEUTSCHLAND 2015, Silver DDC "Good Design 15" Award.



Varian yang tersedia :

• Cat. 218812854 : 125 mL, d36mm, H54mm
• Cat. 218813653 : 250 mL, d66mm, H158mm
• Cat. 218814452 : 500 mL, d78mm, H193mm
• Cat. 218815457 : 1000 mL, d93mm, H253mm



Product Overview

International award winning design. The specially shaped recessed grips on both sides of the bottle ensure easy and safe handling. The slim shape of the YOUTILITY® bottle saves space when used in autoclaves and laboratory refrigerators. The bottles can also be stored horizontally on their side. A specially marked area fits perfectly with the self-adhesive DURAN® YOUTILITY® labels. The bottles are available in sizes 125, 250, 500 and 1000 ml. They are made from the tried and tested DURAN® borosilicate glass 3.3, a neutral glass that corresponds to glass Type 1 according to the European Pharmacopoeia. DURAN® glass offers very high chemical resistance and high temperature resistance.



DURAN® YOUTILITY® GL 45 Laboratory Bottle, amber

with screw cap and pouring ring (PP, cyan), with DIN 168-1 thread, USP <660> (Spectral Transmission) and EP (3.2.1), graduated

• UV protection: USP <660> (Spectral Transmission) and EP (3.2.1) compliant. Less than 10% spectral transmission between 290 nm and 450 nm.
• Manufactured from ambered DURAN® borosilicate glass 3.3. DURAN® is a neutral glass, classified as a Glass Type I according to USP <660>, EP (3.2.1) and JP <7.01>, and meets ASTM E438, Type I, Class A requirements
• The only external application of the colour ensures that internal surfaces have standard DURAN® glass properties. Very durable and chemically resistant amber colour.
• Easier and safer handling with the award winning design. Specially shaped gripping zones on both sides of the bottle.
• Significantly faster opening or closing with the shortened bottle thread which remains fully compatible with GL 45 closures and other accessories
• The optimized, ergonomic shape of the screw cap has comfortable grooves and ridges for a more efficient and easier tightening or removal, especially with smaller sized or gloved hands.
• The pre-defined labelling areas are compatible with the dedicated DURAN® self-adhesive YOUTILITY bottle labels for unambigious bottle identification.
• The slimmer bottle shape allows a more optimal use of limited space in autoclaves and laboratory refrigerators.
• Lot number (Retrace code) for traceability and certificate download at https://cert.dwk.com/
• Award winning product design: Winner of seven international awards: Red Dot 2014, iF 2014, Silver IDEA International Excellence Award 2014, GOOD DESIGN AWARD Japan 2014, Special Mention German Design award 2015, Nominert DESIGNPREIS DER BUNDESREPUBLIC DEUTSCHLAND 2015, Silver DDC "Good Design 15" Award



Varian yang tersedia :

• Cat. 218862859 : 125 mL, d36mm, H54mm
• Cat. 218863658 : 250 mL, d66mm, H158mm
• Cat. 218864457 : 500 mL, d78mm, H193mm
• Cat. 218865453 : 1000 mL, d93mm, H253mm



Product Overview

International award winning design. The specially shaped gripping zones on both sides of the bottle permit easier and safer handling. The slimmer YOUTILITY bottle shape allows a more optimal use of limited space in autoclaves and laboratory refrigerators. The bottles can be conveniently stacked horizontally on their sides. A pre-defined labelling area is compatible with the dedicated self-adhesive YOUTILITY bottle labels. Sequentially sized bottles 125, 250, 500 and 1000 ml. The glass bottles are moulded from the tried and tested DURAN® borosilicate 3.3, a pharmacopoeial Type 1 neutral glass. DURAN® glass offers a very good chemical resistance and high temperature resistance. As an alternative to clear DURAN® glass, the amber coloured glass offers protection against ultraviolet light for light sensitive material, and fully meets the requirements of the USP and Eur. Ph. 3.2.1. The amber colour is permanently fired into the exterior glass surface. The treatment does not affect the properties of the inner surface of the bottle. The amber bottles can be used for the storage or transport of chemicals sensitive to light.



DURAN® YOUTILITY® GL 45 Screw Cap, PP, cyan

Diameter : 53 mm

Height : 25 mm

Catalog no 292292802

• Faster opening and closing thanks to the shortened thread, which is still compatible with all GL 45 laboratory bottles
• The optimized, ergonomic shape of the screw cap has comfortable grooves and ridges for a more efficient and easier tightening or removal, especially with smaller sized or gloved hands
• The tried and tested cap plug sealing with sealing lip system ensures a liquid tight seal



Product Overview

The optimized, ergonomic shape of the screw cap has comfortable grooves and ridges for a more efficient and easier tightening or removal, especially with smaller sized or gloved hands. The inverted cone form of the cap makes bottle handling easier and far safer. The shortened thread inside the cap permits faster opening and closing, yet it is fully compatible with standard DIN GL 45 glass bottle threads. The tried and tested cap plug sealing system ensures a liquid tight seal. A pre-defined labelling area on the cap is compatible with the dedicated DURAN® self-adhesive YOUTILITY label.



DURAN® YOUTILITY® GL 45 Pouring Ring, PP, cyan

Diameter : 53 mm

Catalog no 292412808

• Pouring ring for drip-free pouring
• Cyan colour matches the YOUTILITY GL 45 screw cao
• Fully compatible with the GL-ISO bottle GL 45 necks and therefore highly versatile



Product Overview

The DURAN® YOUTILITY pouring ring is a precision-molded accessory designed to provide a clean, drip-free pouring experience when used with compatible DURAN® YOUTILITY or Original laboratory bottles. It clips securely ontio the bottle neck, allowing liquids to flow smoothly from the bottle without running down the outer wall, thus reducing product loss, contamination risk, and cleanup time. Made from high-quality, autoclavable polypropylene, it withstands repeated sterilization and harsh laboratory conditions, making it suitable for both chemical and biological applications. Matching YOUTILITY screw caps are available separately, allowing color coordination between the cap and ring.



DURAN® YOUTILITY® GL 45 Bottle Tag, silicone rubber

• Available in different colours for identification marking and personalizing laboratory bottles
• The elastic Bottle Tags can be easily and securely attached around the neck, even with the screw cap in place
• Feature a graspable tab that makes them easy to remove with bare or gloved hands
• Chemically robust, heat resistant and totally reusable
• Fully compatible with all the GL 45 threads and therefore highly versatile

Varian Colour Tag Bottle Silicone :

• Red, catalog no 292432818
• Orange, catalog no 292432826
• Yellow, catalog no 292432834
• Green, catalog no 292432842
• Blue, catalog no 292432859
• Purple, catalog no 292432867
• Black, catalog no 292432875
• White, catalog no 292432883



Product Overview

The colourful GL 45 Bottle Tags offer an elegant solution to the marking of laboratory bottles. The Bottle Tags can be easily and securely attached around the neck of the YOUTILITY bottle, even with the screw cap in place. The Bottle Tags feature a graspable tab that makes them easy to remove with bare or gloved hands.
